367.128m2 3 Bedrooms 3.5 Bathrooms 2 Car Garage 2 Storey
DESCRIPTION
This is a modern and unique three bedroom luxury family home.
Large foyer with stunning curved feature staircase
Large open plan kitchen/dining/living - two storey high ceilings over the dining and living
Walk in pantry
One bedroom with built in robe and ensuite
One bedroom with walk in robe and dual access ensuite
Master bedroom featuring massive ensuite with his and hers vanities and feature bath area + huge walk in robe
First floor sitting room
Large first floor void looking over the dining and living rooms
Study
Laundry
Powder room on the ground floor
Outside alfresco
To modify this design please contact us for a FREE quote. Click Here.
Floor Plan Ground Floor
First Floor
All Our Full Working Drawings Sets include the following:
Floor plans
Site plan (if we have your site survey)
Elevations
Sections
Roof plan
Area legend
Door and Window schedule
3D perspectives (black and white)
Additional services we can offer include*:
Wet area details
Construction details
Shadow diagrams
Colour floor plans, elevations and perspectives
Modifications to designs
Electrical Plan
Floor finishes plan
Slab layout plan
*Additional services will be charged at a rate of $132 per hour.
Due to the volatile nature of the Australian construction industry and lack of building materials at the moment, AHDG are unable to provide accurate building prices at this stage.
AHDG recommends purchasing our $99 Dimensioned Floor Plan + Elevations drawings and then contact local builders for pricing. This will be more economical than purchasing full working drawings. Please note, not all builders will be able to provide a quote with the $99 plans. They may require full working drawings.
Please contact us if you have any questions
