M5013-B

KEY SPECS

318.5m2       5 Bedrooms       3 Bathrooms       2 Car Garage       2 Storey

DESCRIPTION

This is a downsized version of our M5013-A design.

• Open plan kitchen/dining/living

• Huge Walk in butlers pantry

• Master bedroom with walk in robe, large luxury ensuite including bath and separate toilet

• Three bedrooms with built in robes

• One bedroom with built in robe + dual access ensuite

• Separate kids retreat

• Front balcony

• Downstairs bathroom

• Laundry

• Outside patio with BBQ zone

• Study nook upstairs

To modify this design please contact us for a FREE quote. Click Here.

Floor Plan
Ground Floor

First Floor

All Our Full Working Drawings Sets include the following:

• Floor plans
• Site plan (if we have your site survey)
• Elevations
• Sections
• Roof plan
• Area legend
• Door and Window schedule
• 3D perspectives (black and white)

Additional services we can offer include*:

• Wet area details
• Construction details
• Shadow diagrams
• Colour floor plans, elevations and perspectives
• Modifications to designs
• Electrical Plan
• Floor finishes plan
• Slab layout plan

*Additional services will be charged at a rate of $132 per hour.

Due to the volatile nature of the Australian construction industry and lack of building materials at the moment, AHDG are unable to provide accurate building prices at this stage.

AHDG recommends purchasing our $99 Dimensioned Floor Plan + Elevations drawings and then contact local builders for pricing. This will be more economical than purchasing full working drawings. Please note, not all builders will be able to provide a quote with the $99 plans. They may require full working drawings.

Please contact us if you have any questions
